Veritas Bevel-Up Jointer Planes

The Veritas Bevel-Up Jointer is the largest member of the bevel-up bench plane family. At 560 x 73mm and weighing 3.4kg, it is the answer for jointing edges and flattening large panels. The bevel-up blade configuration results in a plane that is versatile and straightforward to use. The 12° bed angle, coupled with the 25° blade bevel, creates an effective cutting angle of 37°. Simply increasing the blade bevel results in higher cutting angles for improved performance in more difficult grained woods. An adjustable throat plate allows a wide range of mouth adjustment. A unique stop-screw retains mouth settings while preventing blade damage when removing and replacing blades. The lapped blades have a flatness tolerance of ±0.005mm or better over the working surface, and with an average roughness surface finish of 0.000127mm or better. Supplied with a 57mm wide lapped blade, 4.75mm thick in the highly acclaimed PM-V11 alloy steel. Other blades are available as optional extras.-bg
